雙向差分壓力：

-5 .. 5 mbar up to -1000 .. 1000 mbar

差分壓力/表壓：

0 .. 5 mbar up to 0 .. 7000 mbar

絕壓：

0 .. 1000 mbar up to 0 .. 2000 mbar

主要參數(shù)

FEATURES
• Combined pressure sensor and switch
• Calibrated and temperature compensated
• Analog voltage output of 0.5 to 4.5V
(ratiometric)
• Two programmable logic switching outputs
of 0/5 V, configurable as normally open,
normally close or in window mode
• Threshold, hysteresis and delay can be set
individually for each switching output
• Differential/relative, bidirectional differential,
absolute and barometric versions
• High accuracy up to 0.5% at RT
• Small overall error within a temperature
range of -25 ... 85°C
• Supply voltage range 4.75…5.25V
• High long term stability
• Small DIP package
• Ready to use
• RoHS compliant

GENERAL DEscriptION
The pressure sensors/switches in the AMS 5105
series combine a high-precision OEM pressure
sensor with a programmable pressure switch in
one package. AMS 5105 has one analog voltage
output and two independent logic switching
outputs. The analog voltage output is ratiometric to
the supply voltage of 5 V. The switching outputs
are software configurable as normally open,
normally closed or in window mode; thresholds and
hysteresis can be set individually. The pressure
sensors/switches are calibrated and compensated
for across a temperature range of -25 to +85°C.
AMS 5105 comes in a dual in-line package (DIP)
for assembly on printed circuit boards (PCBs). The
electrical connection is made via the DIP solder
pins; pressure is connected via two vertical metal
tubes.
AMS 5105 is available for various applications and
pressure ranges: differential (relative) devices in
ranges from 0…5 mbar up to 0…7 bar, two
absolute pressure variants for 0…1 bar and 0…2
bar and a barometric variant. Bidirectional
differential devices are available in different ranges
from -5…+5 mbar up to -1…+1 bar. Other pressure
ranges or customized modifications are available
on request.

TYPICAL APPLICATIONS
• Pressure measurement/control
• Vacuum measurement/control
• Process control
• Gas flow
• Fluid level measurement
• Medical instrumentation
• Heating, Ventilation and Air Conditioning
(HVAC)
